| Form Factor |
1U rack, Height: 43mm (1.69 inches), Width: 435mm (17.13 inches), Depth: 545mm (21.5 inches) |
| Processor (max) |
1-socket Intel® Xeon® E-2200 processors, up to 8 cores at 95W |
| Memory |
Up to 128GB of 2666MHz TruDDR4 ECC UDIMMs (4 slots) |
| Disk Bays - Maximum Internal Storage |
- 4x 3.5-inch simple- or hot-swap SATA drives
- 4x 2.5-inch simple-swap SATA/SAS drives
- 10x 2.5-inch hot-swap SATA/ SAS/ SSD drives
- 8 x 2.5-inch hot swap SATA/SAS/SSD drives + 2 x 2.5-inch NVMe drives
|
| RAID Support |
- Intel VROC Software RAID supports simple swap and hot swap
- Multiple RAID configurations (common with ThinkSystem)
|
| Power Supply |
Fixed power supply unit 300W Gold, dual redundant AC (450W, Platinum) |
| Network Interface |
2x 1GbE ports embedded, 1x 1GbE dedicated management |
| Expansion Slots |
- 2x PCIe Gen3 x8 slots or 1x PCIe Gen3 x16 slot
- 1x PCIe Gen3 x8 (x4 interface) internal RAID slot
|
| USB Ports/VGA Ports |
- Front: 1x USB 2.0, 1x USB 3.1 Gen1, support XCC mobile
- Rear: 2x USB 3.1 Gen1, 1x Serial COM, 1x VGA
|
| Systems Management |
Lenovo XClarity Administrator with mobile option, support for TPM 2.0 |
| Operating Systems Supported |
Microsoft, Red Hat, SUSE, and VMware ESXi |
| Limited Warranty |
1-year or 3-year warranty |
