| Form Factor |
- 4U chassis: Height: 430mm (16.9 inches), Width: 175mm (6.9 inches), Depth: 566mm (22.3 inches)
- Optional ST250 rack-mount kit
|
| Processors |
1x Intel® Xeon® E-2200 processors, up to 8 cores at 95W. |
| Memory |
Up to 128GB in 4x DIMM slots using 32GB DIMMs 2666MHz TruDDR4 |
| Expansion Slots |
x1 lane PCIe Gen3 in x1 slot; x16 lane PCIe Gen 3 in x16 slot (for GPU); x4 PCIe Gen3 in x4 slot; x4 PCIe Gen3 in x8 slot |
| Drive Bays |
Up to 8x 3.5-inch simple-swap and hot-swap SATA/SAS bays; up to 16x 2.5-inch hot-swap SATA/SAS; 2x 5.25-inch media bay (for optical drive or tape); 1x M.2 support |
| HBA/RAID Support |
Intel VROC Software RAID support; multiple hardware RAID configurations supported |
| I/O Interface |
- 1x front USB 3.1 G1 port and USB 2.0 port for XCC mobile
- 2x rear USB 3.1 G2 ports and 2x rear USB 3.1 G1 ports
- 1x Serial Com port and 1x VGA port
|
| Network Interface |
2x 1GbE ports standard; 1x 1GbE dedicated management port |
| Power |
Dual-redundant 80 PLUS power supply unit (PSU) 550W; fixed PSU 250W; power efficiency up to Platinum; Energy Star 2.1 compliant |
| Systems Management |
Lenovo XClarity Controller; TPM 1.2 embedded (optional to TPM 2.0) |
| Operating Systems |
- Microsoft, SUSE, Red Hat, VMware vSphere. Visit lenovopress.com/osig for more information.
- Microsoft Windows Client OS – Win10 tested
|
| Limited Warranty |
1- and 3-year customer replaceable unit and onsite service, next business day 9x5, optional service upgrades |
